CX06PM 2/2 Way Brass Coaxial Valve Plug-In
CX06PM 2/2 Way Brass Coaxial Valve Plug-In
SKU:ACC-f88d6e
Discover precision and durability with the CX06PM 2/2 Way Brass Coaxial Valve Plug-In. Optimal for industrial applications, it ensures reliable performance at pressures up to 64 bar with a pneumatic actuator and premium seals.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
CX06PM 2/2 Way Brass Coaxial Valve Plug-In
$149.99
Quantity: 1
Claim Your Seller Account
CX06PM 2/2 Way Brass Coaxial Valve Plug-In
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX06PM 2/2 Way Brass Coaxial Valve Plug-In is a high-performance valve designed for precise control in industrial applications. Crafted from durable brass with fluorocarbon and PTFE seals, it ensures reliable operation at pressures up to 64 bar. With a normally closed switching function and pneumatic actuator, this valve offers optimal performance in temperatures ranging from -10°C to 100°C. Ideal for process automation, it guarantees quick installation and superior functionality, making it a trusted choice for institutional buyers seeking top-tier quality and compliance.
Product Specifications
Dimensions Height
7.60 in | 192 mm
Dimensions Length
2.15 in | 55 mm
Specifications 3 Day Lead Time
Yes
Specifications Actuator Type
Pneumatic
Specifications Body Material
Brass
Specifications Division
ACCESSORIES
Specifications Number Of Ways
2/2
Specifications Operating Pressure Max
64 bar | 928 psi
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
64 bar | 928 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Seal Material
Static Seal: Fluorocarbon (FKM)Dynamic Seal: Polytetrafluoroethylene (PTFE)
Specifications Series
CX Plug-In
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 1/2
Specifications Thread Type
BSPP
Specifications Type
2/2 Way Manifold Coaxial Valve Plug-In
Specifications Weight
1.68 kg | 3.68 lb
