CX07PM-2/2-F/C-2/10/120/012-1X Coaxial Valve Plug-In Manifold
CX07PM-2/2-F/C-2/10/120/012-1X Coaxial Valve Plug-In Manifold
SKU:ACC-a07273
High-performance brass Coaxial Valve Plug-In Manifold ideal for industrial applications, offers precise control & durability.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
CX07PM-2/2-F/C-2/10/120/012-1X Coaxial Valve Plug-In Manifold
$129.99
Quantity: 1
Claim Your Seller Account
CX07PM-2/2-F/C-2/10/120/012-1X Coaxial Valve Plug-In Manifold
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX07PM-2/2-F/C-2/10/120/012-1X Coaxial Valve Plug-In Manifold is a top-of-the-line brass valve designed for precision and durability. With a maximum pressure of 120 bar and operating temperatures ranging from -10°C to 100°C, this valve ensures reliable performance in various industrial settings. The dynamic seal made of Polytetrafluoroethylene (PTFE) and static seal of Fluorocarbon (FKM) offer superior resistance to wear and tear. Ideal for pneumatic applications with a switching function of Normally Closed, this valve guarantees optimal control and efficiency. The valve also complies with industry-specific certifications and meets stringent procurement standards, making it a reliable choice for institutional buyers.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Height
7.60 in | 192 mm
Dimensions Length
2.15 in | 55 mm
Specifications 3 Day Lead Time
Yes
Specifications Actuator Type
Pneumatic
Specifications Body Material
Brass
Specifications Division
ACCESSORIES
Specifications Number Of Ways
2/2
Specifications Operating Pressure Max
120 bar | 1740 psi
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
120 bar | 1740 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Seal Material
Static Seal: Fluorocarbon (FKM)Dynamic Seal: Polytetrafluoroethylene (PTFE)
Specifications Series
CX Plug-In
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 1/2
Specifications Thread Type
BSPP
Specifications Type
2/2 Way Manifold Coaxial Valve Plug-In
Specifications Weight
1.671 kg | 3.68 lb
