CX08P-2/2 Brass Manifold Coaxial Valve
CX08P-2/2 Brass Manifold Coaxial Valve
SKU:ACC-9d5ed8
High-performance brass manifold valve for industrial applications, 2/2 way design, max 160 bar pressure.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.

The CX08P-2/2 Brass Manifold Coaxial Valve is a high-performance 2/2 way valve designed for industrial applications. Constructed with durable brass and premium seals, this valve ensures reliable operation under high pressures up to 160 bar. With a pneumatic actuator and BSPP thread type, it offers precise control and efficient switching functions. Measuring 2.27 inches in length and 5.93 inches in height, this valve is a versatile solution for process and automated valve systems.
Product Specifications
Dimensions Height
5.93 in | 150.5 mm
Dimensions Length
2.27 in | 56.3 mm
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Pneumatic
Specifications Body Material
Brass
Specifications Division
ACCESSORIES
Specifications Number Of Ways
2/2
Specifications Operating Pressure Max
160 bar | 2320 psi
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
160 bar | 2320 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Seal Material
Static Seal: Fluorocarbon (FKM)Dynamic Seal: Polytetrafluoroethylene (PTFE)
Specifications Series
CX Plug-In
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 3/8
Specifications Thread Type
BSPP
Specifications Type
2/2 Way Manifold Coaxial Valve Plug-In
Specifications Weight
1.6 kg | 3.73 lb
