CX08P-2/2-F/C-2/10/160/014 Coaxial Valve Manifold
CX08P-2/2-F/C-2/10/160/014 Coaxial Valve Manifold
SKU:ACC-a7ad64
High-performance CX Series Coaxial Valve Manifold for precise fluid control. Brass body, max pressure: 160 bar | 2320 psi. Ideal for industry standards.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
CX08P-2/2-F/C-2/10/160/014 Coaxial Valve Manifold
$149.99
Quantity: 1
Claim Your Seller Account
CX08P-2/2-F/C-2/10/160/014 Coaxial Valve Manifold
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX08P-2/2-F/C-2/10/160/014 Coaxial Valve Manifold is a high-performance solution designed for efficient fluid control applications. Constructed with brass body material and premium seals such as Fluorocarbon (FKM) and Polytetrafluoroethylene (PTFE), this 2/2 way plug-in valve ensures reliable operation at a maximum pressure of 160 bar | 2320 psi. With a pneumatic actuator and a normally closed switching function, this valve offers precise and responsive control. It meets industry-specific certifications and standards, making it a trusted choice for both consumer and institutional buyers.
Product Specifications
Dimensions Height
5.93 in | 150.5 mm
Dimensions Length
2.27 in | 56.3 mm
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Pneumatic
Specifications Body Material
Brass
Specifications Division
ACCESSORIES
Specifications Number Of Ways
2/2
Specifications Operating Pressure Max
160 bar | 2320 psi
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
160 bar | 2320 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Seal Material
Static Seal: Fluorocarbon (FKM)Dynamic Seal: Polytetrafluoroethylene (PTFE)
Specifications Series
CX Plug-In
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 1/4
Specifications Thread Type
BSPP
Specifications Type
2/2 Way Manifold Coaxial Valve Plug-In
Specifications Weight
1.6 kg | 3.73 lb
