CXKM-2/2-FC-6/25 Coaxial Angle Seat Valve 24V
CXKM-2/2-FC-6/25 Coaxial Angle Seat Valve 24V
SKU:ACC-b2c44a
High-performance CXKM-2/2-FC-6/25 Coaxial Angle Seat Valve for reliable industrial operations.
Regular price
$139.99
Regular price
Sale price
$139.99
Unit price
per
Initiate Order
CXKM-2/2-FC-6/25 Coaxial Angle Seat Valve 24V
$139.99
Quantity: 1
Claim Your Seller Account
CXKM-2/2-FC-6/25 Coaxial Angle Seat Valve 24V
$139.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Meet all your industrial valve needs with the CXKM-2/2-FC-6/25 Coaxial Angle Seat Valve. Featuring BSPP thread type, piston valve design, and suitable for gaseous, liquid, and contaminated media. With a maximum pressure of 20 bar, operating temperatures from -10 to 100°C, electric actuator, and IP65 degree of protection, this valve ensures reliable performance in diverse applications with no orientation restrictions.
Product Specifications
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Electric
Specifications Back Pressure Max
16 bar | 232 psi
Specifications Degree Of Protection
IP 65 When Fitted with Connector Plug
Specifications Flow Direction
As Marked
Specifications Media
Gaseous, Liquid, Contaminated
Specifications Mounting Position
No Orientation Restrictions
Specifications Number Of Ways
2/2
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
20 bar | 290 psi
Specifications Switching Function
Normally Closed
Specifications Thread Type
BSPP
Specifications Type
Piston Valve
Specifications Voltage
24 V
