D3000 Series Low Pressure Pneumatic Actuator with Positioner
D3000 Series Low Pressure Pneumatic Actuator with Positioner
SKU:ACT-86b62f
Reliable D3000 Series Pneumatic Actuator for precise control in industrial settings. All-aluminum housing, agency recognized, UL certified for fire applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
D3000 Series Low Pressure Pneumatic Actuator with Positioner
$349.99
Quantity: 1
Claim Your Seller Account
D3000 Series Low Pressure Pneumatic Actuator with Positioner
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The D3000 Series Low Pressure Pneumatic Actuator is a high-quality solution designed for precision control in industrial applications. Featuring an all-aluminum housing and telescoping linkage, this actuator ensures long-lasting reliability. With a spring range of 8 to 13 psi and maximum control pressure of 25 psi, it offers fast and flexible installation. Recognized by leading agencies, this actuator is UL recognized for fire and smoke applications up to 250°F (121°C), making it a dependable choice for critical environments. With over a million units in service, this actuator guarantees full power delivery and efficient performance.
Product Specifications
Specifications Actuator Air Consumption
2 SCIM
Specifications Ambient Operating Temperature
-20 to 150 ºF | -29 to 66 ºC
Specifications Benefits
Provides a lightweight, robust actuatorProvides fast, flexible installationPlaces over a million actuators now in serviceEnsures full power deliveryProvides a UL recognized component for fire and smoke applications to 250ºF (121ºC)
Specifications Body Material
Die Cast Aluminum
Specifications Diaphragm Material
Synthetic Elastomer
Specifications Effective Diaphragm Area
15 in²
Specifications Features
All-aluminum HousingTelescoping LinkageLong Life and Reliable Design2-way Swivel HeadAgency Recognition
Specifications Maximum Control Pressure
25 psi
Specifications Nominal Control Pressure
20 psi
Specifications Positioner Air Consumption Optional
5 SCIM
Specifications Shipping Weight W Positioner
10 lbs
Specifications Spring Range
8 to 13 psi
Specifications Stroke
3 in
