Robust and powerful handheld instrument for coating thickness measurement on ferrous substrates according to the magnetic induction method (DIN EN ISO 2178) with interchangeable probes. Supports the FPR1 profile probe for determining the depth of surface profiles according to ASTM 4471.
Product Specifications
Additional Information
The portable DMP10 represent precise measurement technology and are ideal for samples and control measurement. These user-friendly and sturdy instruments can be adapted to all requirements of coating thickness measurement using exchangeable measuring probes. The most significant statistical values are displayed and can be stored together with the calibration in the instrument, ensuring quick and reliable operation.
Instrument Features
- Ergonomic aluminum housing- Shockproof, dustproof and waterproof (IP64)- One-handed operation via 4 keys for optimal work- Visual, haptic and acoustic signal for user-defined limit values of specific or all parameters- High contrast, color rotating display for any viewing angle- Robust probe connector- USB interface for secure and fast data transfer- Rechargeable Lithium battery with up to 24 hours of run time - Intuitive menu navigation- Graphic operating aids guide the user through each step of the process- Memory capacity for 10,000 values- Support of digital probes and F-probes (with optional DMP-F-PROBE-ADAPTER)- 22 languages can be set- External charger not included (optionally available)
Measurement Strategies And Evaluation
Magnetic induction method
Specifications Industry Standardscertifications
American Society for Testing and Materials (ASTM D7091) | European Standards International Organization for Standardization (DIN EN ISO 2178)
Specifications Intended Application
Coating Thickness
Specifications Interfaces
Universal Serial Bus (USB-C)
Specifications Measurement Method
Magnetic induction method
Specifications Memory Readings
0 to 10000
Specifications Probes
Exchangeable
Specifications Storable Measuring Applications
1
