Destaco 40lb Right Swing Power Clamp
Destaco 40lb Right Swing Power Clamp
SKU:POW-9b882f
Secure and precise Destaco 40lb Right Swing Power Clamp for industrial applications. Superior clamping force at 100 psi.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Destaco 40lb Right Swing Power Clamp
$249.99
Quantity: 1
Claim Your Seller Account
Destaco 40lb Right Swing Power Clamp
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Destaco 40lb Right Swing Power Clamp is a versatile solution for secure clamping in industrial applications. With a 28.7mm total stroke and a 98.3mm body length, this double-acting pneumatic swing clamp offers precise control and durability. Operate with ease as it provides a powerful clamping force of 40 lb at a maximum operating pressure of 100 psi. The right swing direction and 10-32 port size make it ideal for various fastening needs. Trust in the quality of Destaco for reliable performance and efficiency.
Product Specifications
Body Dimensions Body Length
98.3 mm
Body Dimensions Body Width
32 mm
Technical Specs Brands
Destaco
Technical Specs Clamping Force
40 lb
Technical Specs Manufacturer Part Number
035-132-190
Technical Specs Maximum Operating Pressure
100 psi
Technical Specs Minimum Order
1
Technical Specs Number Of Packages
1
Technical Specs Operating Volume
1.06 in³
Technical Specs Swing Clamp Port Size
10-32
Technical Specs Swing Direction
Right
Technical Specs Thread Type
National Pipe Thread (NPT)
Technical Specs Total Stroke
28.7 mm
Technical Specs Unspsc Code
23153000
