Destaco 90 lb Right Swing Power Clamp
Destaco 90 lb Right Swing Power Clamp
SKU:POW-322608
Experience precision and power with the Destaco 90 lb Right Swing Power Clamp. Ideal for industrial applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Destaco 90 lb Right Swing Power Clamp
$349.99
Quantity: 1
Claim Your Seller Account
Destaco 90 lb Right Swing Power Clamp
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Destaco 90 lb Right Swing Power Clamp is a high-performance solution for industrial applications. With a robust clamping force of 90 lb and a total stroke of 31.75mm, this double-acting pneumatic clamp ensures secure and precise positioning. Its 1/8 NPT port, 130 psi maximum operating pressure, and right-hand swing direction offer versatility and ease of use. The compact design, with a body length of 104.39 mm and body width of 38.1 mm, makes it ideal for space-constrained environments, while meeting the standards required for government and institutional procurement.
Product Specifications
Body Dimensions Body Length
104.39 mm
Body Dimensions Body Width
38.1 mm
Technical Specs Brands
Destaco
Technical Specs Clamping Force
90 lb
Technical Specs Manufacturer Part Number
8315-LA
Technical Specs Maximum Operating Pressure
130 psi
Technical Specs Minimum Order
1
Technical Specs Number Of Packages
1
Technical Specs Operating Volume
2.01 in³
Technical Specs Swing Clamp Port Size
1/8 in
Technical Specs Swing Direction
Right
Technical Specs Thread Type
National Pipe Thread (NPT)
Technical Specs Total Stroke
31.75 mm
Technical Specs Unspsc Code
23153000
Technical Specs Upc Code
697437583178
