Destaco Left Swing Power Clamp
Destaco Left Swing Power Clamp
SKU:POW-7a8fdc
Experience the robust 27 lbs clamping force of the Destaco Left Swing Power Clamp, designed for precise and secure fastening in industrial applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Destaco Left Swing Power Clamp
$129.99
Quantity: 1
Claim Your Seller Account
Destaco Left Swing Power Clamp
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Destaco Left Swing Power Clamp offers a robust clamping force of 27 lbs, ideal for secure fastening in industrial applications. With a precision-engineered body dimensions of 70.1mm length and 24.89mm width, this double-acting pneumatic clamp ensures efficient operation. Designed for left-hand swing direction and featuring a 10-32 port size, this clamp guarantees reliable performance. Operating at a maximum of 100 psi with a minimal stroke of 26.42mm, it combines strength and precision for versatile use in various industries.
Product Specifications
Body Dimensions Body Length
70.1 mm
Body Dimensions Body Width
24.89 mm
Technical Specs Brands
Destaco
Technical Specs Clamping Force
27 lb
Technical Specs Manufacturer Part Number
035-125-290
Technical Specs Maximum Operating Pressure
100 psi
Technical Specs Minimum Order
1
Technical Specs Number Of Packages
1
Technical Specs Operating Volume
0.54 in³
Technical Specs Swing Clamp Port Size
10-32
Technical Specs Swing Direction
Left
Technical Specs Thread Type
National Pipe Thread (NPT)
Technical Specs Total Stroke
26.42 mm
Technical Specs Unspsc Code
23153000
