Destaco Left Swing Power Clamp - 27 lb Clamping Force
Destaco Left Swing Power Clamp - 27 lb Clamping Force
SKU:POW-206c06
Destaco Left Swing Power Clamp - 27 lb Clamping Force, 66.55mm x 24.89mm, Double-Acting Pneumatic Clamp
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Destaco Left Swing Power Clamp - 27 lb Clamping Force
$129.99
Quantity: 1
Claim Your Seller Account
Destaco Left Swing Power Clamp - 27 lb Clamping Force
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience unparalleled clamping power with the Destaco Left Swing Power Clamp, featuring a robust 27 lb clamping force and precise 66.55mm body length by 24.89mm body width dimensions. This double-acting pneumatic swing clamp with a 10-32 port size ensures efficient operation and reliable performance. With a maximum operating pressure of 100 psi and complying with industry-specific certifications, this clamp is ideal for diverse applications requiring secure and accurate clamping.
Product Specifications
Body Dimensions Body Length
66.55 mm
Body Dimensions Body Width
24.89 mm
Technical Specs Brands
Destaco
Technical Specs Clamping Force
27 lb
Technical Specs Manufacturer Part Number
035-225-290
Technical Specs Maximum Operating Pressure
100 psi
Technical Specs Minimum Order
1
Technical Specs Number Of Packages
1
Technical Specs Operating Volume
0.55 in³
Technical Specs Swing Clamp Port Size
10-32
Technical Specs Swing Direction
Left
Technical Specs Thread Type
National Pipe Thread (NPT)
Technical Specs Total Stroke
26.67 mm
Technical Specs Unspsc Code
23153000
