Destaco Right Swing Power Clamp
Destaco Right Swing Power Clamp
SKU:POW-329b0e
Experience the precision of the Destaco Right Swing Power Clamp with 27 lb clamping force, ideal for secure fastening in industrial applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Destaco Right Swing Power Clamp
$129.99
Quantity: 1
Claim Your Seller Account
Destaco Right Swing Power Clamp
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Destaco Right Swing Power Clamp offers a robust clamping force of 27 lbs, with a precision-engineered body measuring 70.1mm in length and 24.89mm in width. This double-acting pneumatic swing clamp features a 26.42mm total stroke, 10-32 port size, and operates at a maximum pressure of 100 psi. Designed for efficiency and durability, this clamp ensures secure and reliable fastening in industrial applications, meeting stringent quality standards for performance and reliability.
Product Specifications
Body Dimensions Body Length
70.1 mm
Body Dimensions Body Width
24.89 mm
Technical Specs Brands
Destaco
Technical Specs Clamping Force
27 lb
Technical Specs Manufacturer Part Number
035-125-190
Technical Specs Maximum Operating Pressure
100 psi
Technical Specs Minimum Order
1
Technical Specs Number Of Packages
1
Technical Specs Operating Volume
0.54 in³
Technical Specs Swing Clamp Port Size
10-32
Technical Specs Swing Direction
Right
Technical Specs Thread Type
National Pipe Thread (NPT)
Technical Specs Total Stroke
26.42 mm
Technical Specs Unspsc Code
23153000
