The DIAMOND DC-1300-i3-R10 is a rugged embedded computer designed for basic industrial applications, featuring an Intel® Core™ i3-N305 processor for enhanced computing power. With a compact and robust design, this entry-level device offers maximum expansion flexibility, supporting up to 16GB DDR5 memory and various storage options. It meets stringent industrial standards with wide temperature operation (-40 to 70°C), wide voltage input (9-48 VDC), and compliance with MIL-STD-810H for reliability across diverse environments.
Product Specifications
Additional Information Additional Information
4.5X performanceThe Intel® Core⢠i3-N305 processor (Alder Lake-N) option boasts 4.5 times the computing performance of the previous generation model, and features a DDR5 memory slot and multiple storage options (2.5" HDD/SSD, Half-Slim SSD, M.2 SSD, etc.) to flexibly meet various application needs.Compact design for flexible installationThe compact size of only 185 x 131 x 56.5 mm is suitable for space-constrained installs and it supports various installation methods, including wall mount, side mount and DIN-Rail.Complete wireless solutionA full range of wireless transmission options, including GSM, GNSS and Wi-Fi, are supported through the built-in SIM card slot, M.2 Key B slot, or M.2 Key E slot (using an adapter to convert from M.2 Key B).Rich expandabilityThe new stackable expansion box (SEB) adds support for more I/O, CANbus, and Fieldbus modules via the DC-1300's dual M.2 B Key slots, while CMI/CFM technology enables extra I/O ( COM, DIO, display), and IGN functions.International certificationIndustrial-grade protection supports wide temperatures (-40 to 70°C) and wide voltages (9-48 VDC), and passes the EMC standard for industrial environments (IEC 61000-6-2/61000-6-4). US military standard (MIL-STD-810H) ensure reliable operation across various application scenarios.
Audio Audio Codec
Realtek® ALC888, High Definition Audio
Audio Line Out
1x Line-out, Phone Jack 3.5mm
Audio Mic In
1x Mic-in, Phone Jack 3.5mm
Environment Electromagnetic Compatibility Emc
European Conformity (CE) | Federal Communications Commission (FCC) | Interference-Causing Equipment Standard 003 (ICES-003 Class A) | United Kingdom Conformity Assessed (UKCA)
Environment Electromagnetic Interference Emi
CISPR 32 Conducted & Radiated: Class AEN/BS EN 55032 Conducted & Radiated: Class AEN/BS EN IEC 61000-3-2 Harmonic current emissions: Class AEN/BS EN61000-3-3 Voltage fluctuations & flickerFCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
Environment Environmental Management System Ems
EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kVEN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 10 V/mEN/IEC 61000-4-4 EFT: AC Power: 2 kV; DC Power: 1 kV; Signal: 1 kVEN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kVEN/IEC 61000-4-6 CS: 10V (Compliant with the standard when utilizing shielded ethernet cable.)EN/IEC 61000-4-8 PFMF: 50 Hz, 30A/mEN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 1 cycles at 60 Hz
Environment Industrial Environment
EMCEN/BS/IEC 61000-6-4: 2019 Class AEN/BS/IEC 61000-6-2: 2019
Environment Non Condensing Relative Humidity Rh At 60 Degree Cel
95 %
Environment Note For Operating Temperature
PassMark BurnInTest: 100% CPU, 2D/3D Graphics (without thermal throttling) With extended temperature peripherals; Ambient with air flow According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14
Environment Operating Temperature
-40 to 70 ºC
Environment Shock
MIL-STD-810H
Environment Storage Temperature
-40 to 70 ºC
Environment Vibration
MIL-STD-810H
Expansion Combined Multiple Interface Cmi Inputoutput Io
1x CMI Interface for optional Display or I/O Module Expansion1x CMI Interface for optional I/O Module Expansion
Expansion Control Function Module Cfm Interface
1x CFM Interface for optional IGN Module Expansion
Expansion M2 Key B Socket
1x M.2 Key B Type 3042/3052 Socket (PCIe Gen 3x1/ USB3.2 Gen2 x1 / SATA), Support 5G/Storage/Add-on Card Expansion1x M.2 Key B Type 2242 (PCIe Gen 3x1), Support Add-on Card Expansion
Expansion Subscriber Identity Module Sim Socket
1x Front Accessible Dual Nano SIM Socket
Features Features
Onboard Intel® Alder Lake-N Processor N97 and Core⢠i3-N305 Processor1 x DDR5 SO-DIMM Sockets, Supports up to 4800MHz 16GB Memory1x M.2 Key B Type 3052/3042 Socket for 5G Module Expansion1x M.2 key B Type 2242 Socket for I/O Module ExpansionCMI Technology for Optional I/O Module ExpansionsCFM Technology for Power Ignition Sensing Function
Graphics Displayport Dp
1x DisplayPort Connector (4096 x 2304 at 60 Hz)Verified maximum resolution: 3840 x 2160 at 60 Hz
Graphics Graphics Engine
Integrated Intel® UHD Graphics
Graphics Maximum Display Output
Supports Two Independent Display(Onboard 1x DisplayPort + Optional CMI 1x Display)
Inputoutput Io Ports Communication Port Com
2x RS-232/422/485 with Auto Flow Control (Support 5V/12V), DB9
Inputoutput Io Ports Local Area Network Lan
2x 2.5GbE LAN, RJ45GbE1: Intel® I225GbE2: Intel® I225
Inputoutput Io Ports Universal Serial Bus Usb
2 x USB 3.2 Gen2x1 (10Gbps), Type A1 x USB 3.2 Gen1x1 (5Gbps), Type A1 x USB 2.0 (480Mbps), Type A
Operating System Linux
Ubuntu Desktop 22.04 LTS
Operating System Microsoft Windows
Windows®11 | Windows®10
Other Function Antenna Holes
2x Antenna Holes
Physical Depth
131 mm
Physical Height
56.5 mm
Physical Width
185 mm
Power Inrush Current Peak At 12 Volt V Voltage
4.572 A
Power Maximum Power Consumption
49.4 W
Power Power Button
1x ATX Power On/Off Button
Power Power Input
9 to 48 VDC, 3-Pin Terminal Block
Power Power Mode Switch
1x AT/ATX Mode Switch
Power Remote Power Light Emitting Diode Led
1x Remote Power LED, 2-Pin Terminal Block
Power Remote Power Onoff
1x Remote Power On/Off, 2-pin Terminal Block
Reliability And Protection Over Voltage Protection
Protection Range: 51~58VProtection Type: shut down operating voltage, re-power on at the present level to recover
Reliability And Protection Reverse Power Input
Yes
