DIN 7973/ISO 1483 Metric Steel Zinc Plated Oval Slot Drive Full Thread Self-Tapping Sheet Metal Screw

Name: DIN 7973/ISO 1483 Metric Steel Zinc Plated Oval Slot Drive Full Thread Self-Tapping Sheet Metal Screw
Brand: Aspen Fasteners
SKU: SCR-11c089
Price: 49.99 USD
Availability: OutOfStock

SKU:SCR-11c089

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Sheet Metal Screws, or Self-Tapping Screws, are thread cutting fasteners designed to be driven into untapped holes. They generally require a pre-drilled pilot hole (drill size dependent on the screw diameter and material thickness). They are available with a variety of points and thread styles in order to accommodate different material thickness.

Product Specifications

Additional Information

Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.Oval countersunk head screws are also known as raised countersunk head screws.

Specifications Coating

Zinc Plated

Specifications Coating Color

Clear

Specifications Drive Style

Slotted Drive

Specifications Head Detail

80 Degree Countersink

Specifications Head Style

Oval Countersunk Head

Specifications Industry Standards And Specifications

German Institute for Standardization (DIN 7973) | International Organization for Standardization (ISO 1483)

Specifications Material

Steel

Specifications System Of Measurement

Metric

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread

DIN 7973/ISO 1483 Metric Steel Zinc Plated Oval Slot Drive Full Thread Self-Tapping Sheet Metal Screw
