DIN Butterfly Valve Cast Iron Flanged Long Type DN500
DIN Butterfly Valve Cast Iron Flanged Long Type DN500
SKU:VAL-9a093f
High-quality DN500 Cast Iron DIN Butterfly Valve for reliable shut-off and regulation in diverse applications.
Regular price
$950.00
Regular price
Sale price
$950.00
Unit price
per
Initiate Order
DIN Butterfly Valve Cast Iron Flanged Long Type DN500
$950.00
Quantity: 1
Claim Your Seller Account
DIN Butterfly Valve Cast Iron Flanged Long Type DN500
$950.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series EVFL Gear Operated Cast Iron, Flanged Long Type DIN Butterfly Valve is a robust and versatile valve designed for a wide range of applications. With a size of DN500 (20") and PN16 pressure rating, this valve offers reliable shut-off and regulating functions. It features flange connections, multiple type approvals, and actuation possibilities with gear operation. Constructed with high-quality materials like GG25 Cast Iron and Stainless Steel, this valve ensures durability and efficient performance. The EPDM liner provides excellent sealing properties, meeting the high standards of DIN compliance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications A
486 mm
Specifications Actuation Possibilities
Gear
Specifications Available Type Approvals
ABS | BV | DVGW | FM | GL | KIWA | LRS | RINA | RMRS | WRC
Specifications Body Material
Cast Iron
Specifications C
350 mm
Specifications D
360 mm
Specifications E
413 mm
Specifications F
25 mm
Specifications Flange Connections
PN 16
Specifications G
50 mm
Specifications H Diameter
30 mm
Specifications Iso 5211
F14
Specifications K
140 mm
Specifications L
175 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM)
Specifications M Diameter
17 mm
Specifications N Number Of Holes
4
Specifications Pressure
PN 16
Specifications Shaft Material
Stainless Steel 1.4462
Specifications Size
DN500 - 20" | 500 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
230.0 kg
Specifications X
337 mm
Specifications Y
68 mm
