DIN Cast Iron Lift Check Valve, PN 16 Angle Pattern
DIN Cast Iron Lift Check Valve, PN 16 Angle Pattern
SKU:VAL-9801ad
Reliable DIN PN 16 Cast Iron Lift Check Valve for hydraulic applications. Compliant with Federal procurement standards and industry certifications.
Regular price
$159.99
Regular price
Sale price
$159.99
Unit price
per
Initiate Order
DIN Cast Iron Lift Check Valve, PN 16 Angle Pattern
$159.99
Quantity: 1
Claim Your Seller Account
DIN Cast Iron Lift Check Valve, PN 16 Angle Pattern
$159.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DIN Cast Iron Lift Check Angle Pattern Valve is constructed with a Cast Iron body and Stainless Steel disc and seat, meeting stringent DIN 3202-F1 and F8 standards. Designed for hydraulic applications, this valve ensures reliable performance with handwheel actuators. It complies with Federal procurement standards, GSA requirements, and industry-specific certifications, making it ideal for government and institutional buyers.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Actuators
Handwheel
Specifications Body Material
Cast Iron
Specifications C
145 mm
Specifications Connection
Flanged Drilled
Specifications D
185 mm
Specifications Disc Material
Stainless Steel
Specifications H
18 mm
Specifications Hydraulic Inspection Body
24
Specifications Hydraulic Inspection Seat
16
Specifications Impaissa Code
755861 | 755891
Specifications L1
145 mm
Specifications Number Of Holes
4
Specifications Seat Material
Stainless Steel
Specifications Size
065
Specifications Stem Material
Stainless Steel
Specifications T
18 in
Specifications Weight
16.0 kg
