DIN Cast Steel Overboard Angle Valve - PN16 Spring Loaded
DIN Cast Steel Overboard Angle Valve - PN16 Spring Loaded
SKU:VAL-d0e81f
High-performance DIN Cast Steel Overboard Angle Valve with Spring Actuators for precise hydraulic control in industrial applications.
Regular price
$699.99
Regular price
Sale price
$699.99
Unit price
per
Initiate Order
DIN Cast Steel Overboard Angle Valve - PN16 Spring Loaded
$699.99
Quantity: 1
Claim Your Seller Account
DIN Cast Steel Overboard Angle Valve - PN16 Spring Loaded
$699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DIN Cast Steel Overboard Angle Valve is a premium solution for industrial applications requiring durability and precision. Crafted with Cast Steel GSC-25N2 body, Stainless Steel INOX disc, and stem, this valve ensures reliable performance. Meeting DIN2501-PN16 standards, it offers a secure connection and efficient hydraulic flow control. The seat material is Brass, complementing the Stainless Steel disc for enhanced longevity. With Spring actuators and Flanged Drilled connection, this valve is a cost-effective and dependable choice for various settings.
Product Specifications
Specifications Actuators
Spring
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
285 mm
Specifications D2
200 mm
Specifications Disc Material
Stainless Steel
Specifications H1
575 mm
Specifications Hydraulic Inspection Body
25
Specifications Hydraulic Inspection Seat
16
Specifications L1
225 mm
Specifications Seat Material
Brass
Specifications Size
150
Specifications Stem Material
Brass
Specifications Weight
94 kg
