DIN Hydraulic Male Stud Non Return Valve, BSP Parallel - Body Only

Name: DIN Hydraulic Male Stud Non Return Valve, BSP Parallel - Body Only
Brand: World Wide Metric, Inc.
SKU: VAL-032abf
Price: 49.99 USD
Availability: OutOfStock

SKU:VAL-032abf

Reliable DIN Hydraulic Male Stud Non Return Valve for light-duty applications, nominal operating pressure of 100 bar.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The DIN Hydraulic Male Stud Non Return Valve with Elastomer Seal Thread BSP Parallel - Body Only offers a reliable solution for light-duty applications with a nominal operating pressure of 100 bar. Crafted from durable carbon steel, this valve features a tube diameter of 42.0 mm and precise G - Thread Size of 1 1/2. With dimensions L1: 103.0 mm, L2: 92 mm, L3: 22.0 mm, and CH1: 70 mm, it ensures efficient flow control and secure sealing, making it a crucial component in hydraulic systems.

Product Specifications

Specifications Ch1

70 mm

Specifications Diameter Pass

29 mm

Specifications G Thread Size

1 1/2

Specifications L1

103.0 mm

Specifications L2

92 mm

Specifications L3

22.0 mm

Specifications Material

Carbon Steel

Specifications Nominal Operating Pressure

100 bar

Specifications Pressure

Light Duty

Specifications Tube Diameter

42.0 mm

Category 6

Male Stud Non Return Valve with Elastomer Seal Thread BSP Parallel

DIN Hydraulic Male Stud Non Return Valve, BSP Parallel - Body Only
