DIN PN16 Cast Steel Spring Loaded Globe Valve
DIN PN16 Cast Steel Spring Loaded Globe Valve
SKU:VAL-5b20f3
Precision-engineered DIN PN16 Cast Steel Globe Valve for high-pressure applications. Reliable performance and quick response.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
DIN PN16 Cast Steel Spring Loaded Globe Valve
$299.99
Quantity: 1
Claim Your Seller Account
DIN PN16 Cast Steel Spring Loaded Globe Valve
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DIN PN16 Cast Steel Overboard Spring loaded Globe Valve is a robust solution for industrial fluid control. Constructed with durable Cast Steel body, Stainless Steel disc, and stem, this valve ensures reliable performance under high pressure. Its precise engineering and adherence to DIN2501-PN16 standards guarantee optimal functionality. The spring-loaded design enhances quick response and tight shut-off, making it ideal for demanding applications where safety and efficiency are paramount.
Product Specifications
Specifications Actuators
Spring
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
220 mm
Specifications D2
160 mm
Specifications Disc Material
Stainless Steel
Specifications H
525 mm
Specifications Hydraulic Inspection Body
25
Specifications Hydraulic Inspection Seat
16
Specifications L
350 mm
Specifications Seat Material
Brass
Specifications Size
100
Specifications Stem Material
Brass
Specifications Weight
36.0 kg
