DIN Specialty Cast Steel Angle Valve
DIN Specialty Cast Steel Angle Valve
SKU:VAL-1a5339
Durable PN 16 Cast Steel Angle Valve for industrial applications, meets DIN2501-PN16 standards.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
DIN Specialty Cast Steel Angle Valve
$249.99
Quantity: 1
Claim Your Seller Account
DIN Specialty Cast Steel Angle Valve
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PN 16 Cast Steel Overboard Spring loaded, Angle Valve is a robust and reliable valve designed for industrial applications. Crafted with Cast Steel body, Stainless Steel disc, and stem, this valve ensures durability and longevity. With flanges according to DIN2501-PN16 standards, it offers secure connections and efficient performance. The Brass seat material enhances corrosion resistance, while the Spring actuator provides precise control. This valve is ideal for marine, oil & gas, and industrial settings, meeting stringent procurement requirements.
Product Specifications
Specifications Actuators
Spring
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
165 mm
Specifications D2
100 mm
Specifications Disc Material
Stainless Steel
Specifications H1
380 mm
Specifications Hydraulic Inspection Body
25
Specifications Hydraulic Inspection Seat
16
Specifications L1
125 mm
Specifications Seat Material
Brass
Specifications Size
050
Specifications Stem Material
Brass
Specifications Weight
15.0 kg
