DIN Specialty Valve - PN 16 Cast Steel Spring loaded Angle Valve
DIN Specialty Valve - PN 16 Cast Steel Spring loaded Angle Valve
SKU:VAL-b67bc4
Premium PN 16 Cast Steel Angle Valve with spring-loaded actuators for durable, high-performance industrial use. Compliant with DIN2501 standards.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
DIN Specialty Valve - PN 16 Cast Steel Spring loaded Angle Valve
$299.99
Quantity: 1
Claim Your Seller Account
DIN Specialty Valve - PN 16 Cast Steel Spring loaded Angle Valve
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PN 16 Cast Steel Overboard Spring loaded Angle Valve is a premium choice for industrial applications requiring durability and reliability. Constructed with a cast steel body, stainless steel disc, and stem, this valve ensures longevity and efficient performance under high-pressure conditions. Compliant with DIN2501 standards, the valve offers a secure flanged connection and precise hydraulic inspections. The spring-loaded actuators provide smooth operation, while the brass seat material enhances sealing capabilities, making it ideal for critical processes.
Product Specifications
Specifications Actuators
Spring
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
150 mm
Specifications D2
100 mm
Specifications Disc Material
Stainless Steel
Specifications H1
355 mm
Specifications Hydraulic Inspection Body
25
Specifications Hydraulic Inspection Seat
16
Specifications L1
115 mm
Specifications Seat Material
Brass
Specifications Size
040
Specifications Stem Material
Brass
Specifications Weight
14.0 kg
