Disk Type Check Valves with 10-32 UNF Connection & Coupling Adapter
Disk Type Check Valves with 10-32 UNF Connection & Coupling Adapter
SKU:CHE-634e5c
Reliable Disk Type Check Valves w/ 10-32 UNF Connection & Coupling Adapter - High flow, low pressure loss, and durable design for industrial applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Disk Type Check Valves with 10-32 UNF Connection & Coupling Adapter
$49.99
Quantity: 1
Claim Your Seller Account
Disk Type Check Valves with 10-32 UNF Connection & Coupling Adapter
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Disk Type Check Valves with 10-32 UNF Connection and Coupling Adapter are crafted from 303 SS material, ensuring durability and reliability for both liquid and gas applications. With a maximum operating pressure of 125 psig and a low cracking pressure of 0.5 psig, these valves offer high flow capacity, low pressure loss, and long-life operation. The silicone seal material and low seat leakage of 6 SCCM at over 50 psi make these valves ideal for various industrial settings. Meet your fluid control needs efficiently with our premium disk type check valves.
Product Specifications
Dimensions Outside Diameter
3/8 in
Dimensions Total Length
0.830 in
Features Features
High Flow Capacity Low Pressure Loss Low Cracking Pressure Long Life Operation
Specifications Connection A
10-32 UNF Female
Specifications Connection B
10-32 UNF Female
Specifications Cracking Pressure
0.5 psig
Specifications Cv
0.150
Specifications Disk Material
303 SS
Specifications Material
303 SS
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
225 ºF
Specifications Seal Material
Silicone
Specifications Seat Leakage
6 SCCM (max.) air flow at greater than 50 psi differential
