DME34 Series DC Motor with Gearbox L - High Power and Long Life
DME34 Series DC Motor with Gearbox L - High Power and Long Life
SKU:PER-9c956e
Compact, high-powered DME34 Series Motors with Gearbox L - Long life, high output, and low noise. Ideal for various applications.
Regular price
$179.99
Regular price
Sale price
$179.99
Unit price
per
Initiate Order
DME34 Series DC Motor with Gearbox L - High Power and Long Life
$179.99
Quantity: 1
Claim Your Seller Account
DME34 Series DC Motor with Gearbox L - High Power and Long Life
$179.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DME34 Series Motors with Gearbox L offer a compact size and high power output ranging from 0.7 W to 26 W. With a variety of gear heads available, including 32 Dia to 80 Sq options, these motors are designed for longevity with intermittent operation over 1 million cycles. They boast high output capabilities, heat dissipation, and heat resistance for maximum efficiency. Featuring a robust construction and large diameter output shaft with ball bearings, these motors have high radial load capacity. Additionally, they come with a selection of gear heads, reduction ratios, and optional magnetic revolution sensors and noise filters to meet diverse operational needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information 0
Gear-Head Design | Motor Selection Guide
Customize 0
Custom Designs
Dimensions 0
Specifications Current Rating
100 mA | 0.1 A
Specifications Gear Ratio
150
Specifications L
44.3 mm
Specifications Model Code
SB
Specifications Motor Frame Size
38 x 100 mm | .866 x 3.937 in
Specifications Product Type
DC Motor with Gearbox L
Specifications Rated Output
1.3 W
Specifications Rated Speed
22 r/min
Specifications Rated Torque
48.61 oz·in | 0.34 N·m
Specifications Rated Voltage
24 V
Specifications Series
DME34
Specifications Weight
270 g | 0.6 lb
