DME34 Series Motor with Gearbox 60G - High Power DC Motor
DME34 Series Motor with Gearbox 60G - High Power DC Motor
SKU:PER-42a5bb
Compact yet powerful DME34 Series Motor with Gearbox 60G - ideal for high-performance applications.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
DME34 Series Motor with Gearbox 60G - High Power DC Motor
$299.99
Quantity: 1
Claim Your Seller Account
DME34 Series Motor with Gearbox 60G - High Power DC Motor
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DME34 Series Motor with Gearbox 60G offers exceptional performance with a compact design and high power range of 0.7 W to 26 W. With a variety of gear heads available in sizes ranging from 32 Dia to 80 Sq, this motor ensures versatility for different applications. It boasts a long operating life of over 1 million cycles, high heat dissipation for increased output, and robust construction for high radial load capacity. Additionally, it features low noise operation, improved insulation, and a wide selection of gear heads and reduction ratios to suit various needs. Equipped with a magnetic revolution sensor and noise filter, this motor meets the highest standards of reliability and efficiency.
Product Specifications
Additional Information 0
DME34B6HP.jpg | Gear-Head Design | Motor Selection Guide
Customize 0
Custom Designs
Dimensions 0
Specifications Current Rating
310 mA | 0.31 A
Specifications Frame Size
61 x 61 mm | 2.402 x 2.402 in
Specifications Gear Ratio
300
Specifications Model Code
BB
Specifications Note
6DG gearbox are available with either 4.5 mm diameter mounting holes or M4 x 6 mm tapped holes. Gearboxes with 4.5 mm diameter mounting holes are available from stock. When ordering, please write the motor model and gearbox model numbers separately, as in the following example :DME34B6HPB (Pinion Shaft Motor) 6DG_ (Gearbox) Gearboxes with M4 x 6 mm tapped mounting holes are available on request. When ordering, please write the combine motor and gearbox model, as in the following example: DME34B6H_B
Specifications Product Type
DC Motor with Gearbox 60G
Specifications Rated Output
4.5 W
Specifications Rated Speed
14.8 r/min
Specifications Rated Torque
138.87 oz·in | 0.98 N·m
Specifications Rated Voltage
24 V
Specifications Series
DME34
