DME34 Series Motors with Gearbox 60G - High Power DC Motor
DME34 Series Motors with Gearbox 60G - High Power DC Motor
SKU:PER-243948
Compact, high-power DME34 Series Motors with Gearbox 60G for reliable performance in diverse applications.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
DME34 Series Motors with Gearbox 60G - High Power DC Motor
$299.99
Quantity: 1
Claim Your Seller Account
DME34 Series Motors with Gearbox 60G - High Power DC Motor
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DME34 Series Motors with Gearbox 60G offers a compact size and high power range from 0.7 W to 26 W. With a variety of gear heads available, including 32 Dia-80 Sq options, this motor boasts a long-life operation of over 1 million cycles. Its high output is achieved through superior heat dissipation and heat resistance, resulting in increased strength and radial load capacity. Enjoy low noise operation and improved insulation with new resin brush holders, along with a wide selection of gear heads and reduction ratios to suit various needs. Optionally equipped with a magnetic revolution sensor and noise filter for enhanced functionality.
Product Specifications
Additional Information 0
DME34B6HP.jpg | Gear-Head Design | Motor Selection Guide
Customize 0
Custom Designs
Dimensions 0
Specifications Current Rating
650 mA | 0.65 A
Specifications Frame Size
61 x 61 mm | 2.402 x 2.402 in
Specifications Gear Ratio
75
Specifications Model Code
BA
Specifications Note
6DG gearbox are available with either 4.5 mm diameter mounting holes or M4 x 6 mm tapped holes. Gearboxes with 4.5 mm diameter mounting holes are available from stock. When ordering, please write the motor model and gearbox model numbers separately, as in the following example :DME34B6HPB (Pinion Shaft Motor) 6DG_ (Gearbox) Gearboxes with M4 x 6 mm tapped mounting holes are available on request. When ordering, please write the combine motor and gearbox model, as in the following example: DME34B6H_B
Specifications Product Type
DC Motor with Gearbox 60G
Specifications Rated Output
4.5 W
Specifications Rated Speed
49.3 r/min
Specifications Rated Torque
90.27 oz·in | 0.64 N·m
Specifications Rated Voltage
12 V
Specifications Series
DME34
