DME44 Series Motor with Pulse Generator - 9.2W, 12V

Name: DME44 Series Motor with Pulse Generator - 9.2W, 12V
Brand: Elinco International JPC, Inc.
SKU: PER-1e7440
Price: 89.99 USD
Availability: OutOfStock

SKU:PER-1e7440

Compact, high-powered DC motor with optimized brush design for reliability, high output, and low noise operation.

$89.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The DME44 Series Motor with Pulse Generator is a compact and high-powered DC motor designed for reliability and performance. With a rated output of 9.2W and a rated torque of 24mN·m, this motor offers exceptional strength and durability. It features optimized brush design for extended life, high heat dissipation for increased output, and low noise operation. With a variety of gear heads and reduction ratios available, this motor meets diverse operational needs. Additionally, it is equipped with a magnetic revolution sensor and noise filter for enhanced functionality.

Product Specifications

Additional Information 0

Customize 0

Custom Designs

Dimensions 0

Dimensions | DME44SMA/DME44SMB

Specifications Current Rating

1310 mA | 1.31 A

Specifications Diameter

1.732 in | 44 mm

Specifications Model Code

Specifications No Load Current

0.31 A

Specifications No Load Speed

4300 r/min

Specifications Product Type

DC Motor

Specifications Rated Output

9.2 W

Specifications Rated Speed

3600 r/min

Specifications Rated Torque

24 mNÂ·m | 3.47 ozÂ·in

Specifications Rated Voltage

12 V

Specifications Series

DME44

Specifications Stall Torque

150 mNÂ·m | 22.22 ozÂ·in

Specifications Weight

300 g | 0.66 lb

Torque Curve 0
