DP 30 kW Air Classifier Mill
DP 30 kW Air Classifier Mill
SKU:DPA-4f9373
Experience precise particle reduction with the DP 30 kW Air Classifier Mill, tailored for various industries. Easy to adjust, energy-efficient, and versatile.
Regular price
$28,999.99
Regular price
Sale price
$28,999.99
Unit price
per
Initiate Order
DP 30 kW Air Classifier Mill
$28,999.99
Quantity: 1
Claim Your Seller Account
DP 30 kW Air Classifier Mill
$28,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DP 30 kW Air Classifier Mill, part of the DP Air Classifier Mills line, is a high-speed screen-less vertical hammer mill with an integrated adjustable air classifier. Specifically designed to reduce particles ranging from 8 to 40 microns, this machine combines grinding and classifying into one efficient process. Tailored for powder coating, pharmaceutical, and food production, it offers easy online particle size adjustment, low energy consumption, and a steep particle size distribution. With options for coating mineral powders, protein enrichment, and airflow cooling for heat-sensitive materials, this mill is versatile, easy to clean, and maintain.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Machine Contact and Non-Contact Parts available in Cast Iron, Carbon Steel, 304, 304L, 316, 316L.Wearable parts available in hard materials like Forged Alloy Steel, Welded Hard Facing, Hard Alloy Steel Casting, Cast Iron Internal fan available in single or two-piece design Available in external fan design where airflow control is required.Liners available in water jacketed design to provide cooling in the grinding chamber.
Features And Benefits Features And Benefits
Grinding and Classifying in one machine.Tailored for powder coating, pharma and food production.Easy to clean and maintain.Stepless easy online particle size adjustment.Low specific energy consumption.Suitable for combined grinding and drying.Particularly suitable for frequent product changes.Steep particle size distribution.
Note Note
Made in India
Options And Accessories Options And Accessories
Design for coating of mineral powders.Protein enrichment of flours by size reduction and air classification.Airflow cooling technology for heat sensitive materials.Combined drying and pulverising option.Pressure-shock resistant up to PSR 11 bar.Tangential air inlet.
Specifications Air Flow Rate
4370 m³/h
Specifications Classifier Drive
7.5 kW
Specifications Maximum Classifier Speed 1min
2970 rpm
Specifications Maximum Mill Speed 1min
5770 rpm
Specifications Rotor Drive
30 kW
Specifications Scale Up Factor
3.6 m³/h
