DP AEROVA 1100 Air Classifier
DP AEROVA 1100 Air Classifier
SKU:DPA-503429
Achieve precision particle classification with the DP AEROVA 1100 Air Classifier for industries like minerals, chemicals, and recycling. Maximum speed: 1100 rpm.
Regular price
$15,000.00
Regular price
Sale price
$15,000.00
Unit price
per
Initiate Order
DP AEROVA 1100 Air Classifier
$15,000.00
Quantity: 1
Claim Your Seller Account
DP AEROVA 1100 Air Classifier
$15,000.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DP AEROVA 1100 Air Classifier is a high-efficiency air classifier designed for precise classification of dry materials in the range of 1-150 microns. With a maximum speed of 1100 rpm and a throughput capacity ranging from 5 kgs to 10 tonnes per hour, this forced-vortex unit offers accurate particle sorting for industries such as minerals, chemicals, metal powders, ceramics, plastics, and recycling. Its robust construction, low power consumption, and adjustable secondary air-wash system ensure optimal classification efficiency and long service life.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features And Benefits Features And Benefits
High-efficiency air classifier.Particle size cut-point from 1-150 microns.Precise on-stream control of cut-point by variation of rotor speed and airflow.Low power consumption and Robust construction and build quality for long service life.Adjustable secondary air-wash system for optimisation of classification efficiency.Operates under negative pressure promoting dust-free environment.Can be supplied with a variety of liners and coatings to improve wear resistance.
Note Note
Made in India
Options And Accessories Options And Accessories
Machine Contact and Non-Contact Parts available in Cast Iron, Carbon Steel, 304, 304L, 316, 316L.The internal surfaces of the classifier can be lined with ceramic tiles of various grades.Wearable parts available in hard materials like Forged Alloy Steel, Welded Hard Facing, Hard Alloy Steel Casting, Cast lron.The classifying wheel can also be made of wear resistant materials such as ceramic or silicon carbide.
Specifications Main Drive Motor
22 to 33 kW
Specifications Maximum Speed
1100 rpm | 42000 m³/h
Specifications Pressure Differential
330 mm/SWG
