DualVee® Size 2 Carbon Steel Guide Rail

Name: DualVee® Size 2 Carbon Steel Guide Rail
Brand: Linemaster Switch Corp.
SKU: HER-46268d
Price: 189.99 USD
Availability: OutOfStock

SKU:HER-46268d

Premium DualVee® Size 2 Carbon Steel Guide Rail - Induction hardened, precise alignment, 21 holes, optimal durability.

$189.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The DualVee® Size 2 Carbon Steel Guide Rail is meticulously engineered for precision and durability. Featuring 90° vee way surfaces, induction-hardened for resilience, and a mounting shoulder for effortless alignment. This 60.63-inch guide rail with 21 holes offers versatility, with options for custom finishes and lengths. Crafted from 1045 Carbon Steel meeting American Iron and Steel Institute standards.

Product Specifications

Specifications Circuit

SPDT DB

Specifications Constructionstandards

NEMA Type 2, 4 & 13UL Enclosure 2, 4 & 13CSA Enclosure 2, 4 & 13EN 60529 Degree of Protection IP56

Specifications Electrical Rating

Heavy pilot duty 250 Vac max. | 15 A 125-250 VAC | 1/2 H.P. 125 VAC | 1 H.P. 250 VAC

Specifications Features

DriptightDusttightWatertightOiltight

Specifications Form

Specifications Remarks

DB Double break model must be wired to equal voltage sources and the same polarity. The loads should be on the same sides of the line.

Specifications Size

9 x 5 3/4 x 4 3/4 Inch

Specifications Stages

Two

Specifications Weight Approx

8 lbs
