DualVee® Size 2 Carbon Steel Single Edge Drilled Guide Rail - 72.63 in
DualVee® Size 2 Carbon Steel Single Edge Drilled Guide Rail - 72.63 in
SKU:HER-6a9011
Durable DualVee® Size 2 Carbon Steel Guide Rail with 25 mounting holes, perfect for precision installations
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
DualVee® Size 2 Carbon Steel Single Edge Drilled Guide Rail - 72.63 in
$129.99
Quantity: 1
Claim Your Seller Account
DualVee® Size 2 Carbon Steel Single Edge Drilled Guide Rail - 72.63 in
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DualVee® Size 2 Carbon Steel Single Edge Drilled Guide Rail is designed for precision and durability. Featuring 90º vee way surfaces, this rail is compatible with DualVee® guide wheels. Induction-hardened to a minimum of Rc 53, it offers exceptional durability while allowing for easy machining below the mounting shoulder. With 25 0.203" diameter mounting holes and an integrated mounting shoulder, this rail ensures rapid alignment during installation. Made of 1045 Carbon Steel, meeting American Iron and Steel Institute standards, it is ideal for a wide range of guiding applications. Options for black oxide, thin dense chrome, or nickel plating are available. Customize hole patterns and lengths are also possible upon request.
Product Specifications
Specifications Circuit
DPDT DB
Specifications Constructionstandards
NEMA Type 2, 4 & 13UL Enclosure 2, 4 & 13CSA Enclosure 2, 4 & 13EN 60529 Degree of Protection IP56
Specifications Electrical Rating
Heavy pilot duty 250 Vac max. | 15 A 125-250 VAC | 1/2 H.P. 125 VAC | 1 H.P. 250 VAC
Specifications Features
DriptightDusttightWatertightOiltight
Specifications Form
Z
Specifications Remarks
One pole of these model has an adjustable mechanism that enables you to make or break one pole before the other. â DB Double break model must be wired to equal voltage sources and the same polarity. The loads should be on the same sides of the line.
Specifications Size
9 x 5 3/4 x 4 3/4 Inch
Specifications Stages
Single
Specifications Weight Approx
8 lbs
