DualVee Carbon Steel Single Edge Drilled Guide Rail - Size 3, 24.75 inch
DualVee Carbon Steel Single Edge Drilled Guide Rail - Size 3, 24.75 inch
SKU:HER-a0b369
Durable DualVee Size 3 Carbon Steel Guide Rail, 24.75", with 9 Mounting Holes & Mounting Shoulder. AISI Compliant.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
DualVee Carbon Steel Single Edge Drilled Guide Rail - Size 3, 24.75 inch
$45.99
Quantity: 1
Claim Your Seller Account
DualVee Carbon Steel Single Edge Drilled Guide Rail - Size 3, 24.75 inch
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DualVee Size 3 Carbon Steel Single Edge Drilled Guide Rail is designed with 90º vee way surfaces for optimal compatibility with DualVee guide wheels. Induction hardened to a minimum of Rc 53, this 24.75-inch guide rail offers exceptional durability. Featuring 9 0.281" diameter mounting holes and a mounting shoulder for precise alignment, this product is perfect for effortless installation and accurate positioning. Compliant with AISI standards, this general-purpose guide rail is a reliable and versatile choice for various applications. Optional finishes available upon request.
Product Specifications
Specifications Circuit
SPDT DB
Specifications Constructionstandards
NEMA Type 2, 4 & 13UL Enclosure 2, 4 & 13CSA Enclosure 2, 4 & 13EN 60529 Degree of Protection IP56
Specifications Electrical Rating
Heavy pilot duty 250 Vac max. | 1/2 H.P. 125 VAC | 1 H.P. 250 VAC | 15A 125-250 VAC
Specifications Features
DriptightDusttightWatertightOiltight
Specifications Form
Z
Specifications Remarks
DB Double break model must be wired to equal voltage sources and the same polarity. The loads should be on the same sides of the line.
Specifications Size
9 x 5 3/4 x 4 3/4 Inch
Specifications Stages
Single
Specifications Weight Approx
8 lbs
