DualVee Size 3 Single Edge Guide Rail, Carbon Steel, 12.75in
DualVee Size 3 Single Edge Guide Rail, Carbon Steel, 12.75in
SKU:HER-8b2d22
Precision-engineered Single Edge Guide Rail for smooth linear motion, 1045 carbon steel, 12.75in length, 5 mounting holes
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
DualVee Size 3 Single Edge Guide Rail, Carbon Steel, 12.75in
$39.99
Quantity: 1
Claim Your Seller Account
DualVee Size 3 Single Edge Guide Rail, Carbon Steel, 12.75in
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DualVee Size 3 Single Edge Drilled Guide Rail is a precision-engineered solution designed for smooth and accurate linear motion systems. Crafted from hardened 1045 carbon steel with induction-hardened vee surfaces, this 12.75-inch rail features 5 mounting holes for easy installation. The integrated mounting shoulder ensures precise alignment while maintaining durability. Compliant with American Iron and Steel Institute standards, this rail is ideal for a wide range of guided linear motion applications, providing reliability and performance.
Product Specifications
Specifications Circuit
DPDT
Specifications Constructionstandards
NEMA Type 2, 4 & 13UL Enclosure 2, 4 & 13CSA Enclosure 2, 4 & 13EN 60529 Degree of Protection IP56
Specifications Electrical Rating
20 A 125-250 VAC | 1 H.P. 125-250 VAC | Heavy pilot duty 250 Vac max.
Specifications Features
DriptightDusttightWatertightOiltight
Specifications Form
C
Specifications Remarks
One pole of these model has an adjustable mechanism that enables you to make or break one pole before the other.
Specifications Size
9 x 5 3/4 x 4 3/4 Inch
Specifications Stages
Single
Specifications Weight Approx
8 lbs
