DualVee Studded Guide Wheel - Size 1 Carbon Shielded Wheel Studded

Name: DualVee Studded Guide Wheel - Size 1 Carbon Shielded Wheel Studded
Brand: Linemaster Switch Corp.
SKU: EXP-147197
Price: 49.99 USD
Availability: OutOfStock

SKU:EXP-147197

Precision guide wheel with AISI 303 stainless steel for reliable performance in guiding applications.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The DualVee Studded Guide Wheel Size 1 features precision ground double 90-degree running surfaces, a carbon steel body, and a permanently attached threaded stud for secure positioning. Crafted from AISI 303 stainless steel, this guide wheel is ideal for general guiding applications, ensuring smooth and reliable performance. Compliant with American Iron and Steel Institute (AISI) standards, this wheel meets the stringent quality requirements of institutional and government buyers.

Product Specifications

Specifications Circuit

SPDT

Specifications Connector Wired

Pin A-Normally Opened | Pin B-Common | Pin C-Normally Closed | Pin D-Ground

Specifications Constructionstandards

Class I, Division 1, Group C & DClass I, Zone 1, Group IIA & IIBNema Type 7CEN 60529 Degree of Protection IP41

Specifications Electrical Rating

5 A 125-250 VAC | 3 A 28 VDC Momentary Contact

Specifications Form

Specifications Remarks

Mating connector with cable clamp available from LINEMASTER. Order as catalog Number LSC-835.

Specifications Size

10 x 9 3/4 x 4 3/8 Inch

Specifications Style

Single pedal

Specifications Weight Approx

6 1/2 lbs
