DualVee® Size 3 Carbon Steel Drilled Guide Rail
DualVee® Size 3 Carbon Steel Drilled Guide Rail
SKU:HER-ca1aa5
Optimize linear motion with the DualVee® Size 3 Carbon Steel Drilled Guide Rail, designed for precision and versatility.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
DualVee® Size 3 Carbon Steel Drilled Guide Rail
$89.99
Quantity: 1
Claim Your Seller Account
DualVee® Size 3 Carbon Steel Drilled Guide Rail
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DualVee® Size 3 Carbon Steel Drilled Guide Rail is a versatile solution for precise linear motion applications. Featuring 90º vee way surfaces compatible with DualVee® guide wheels, this guide rail offers rapid alignment with its integrated mounting shoulder. Made from soft, unhardened 1045 Carbon Steel, it allows for drilling and machining as needed. With 17 0.281" diameter mounting holes and a length of 48.75 inches, this guide rail is polished, oiled, and can be customized with various finish options. Engineered with accuracy in mind, this rail ensures smooth and reliable performance in diverse settings.
Product Specifications
Specifications Circuit
SPDT
Specifications Constructionstandards
NEMA Type 2, 4 & 13UL Enclosure 2, 4 & 13CSA Enclosure 2, 4 & 13EN 60529 Degree of Protection IP56
Specifications Electrical Rating
1 H.P. 125-250 VAC | Heavy pilot duty 250 Vac max. | 20A 125-250 VAC
Specifications Features
DriptightDusttightWatertightOiltight
Specifications Form
C
Specifications Size
9 x 5 3/4 x 4 3/4 Inch
Specifications Stages
Single
Specifications Weight Approx
8 lbs
