Ductile Iron Lever Operated Butterfly Valve DN125 PN6
Ductile Iron Lever Operated Butterfly Valve DN125 PN6
SKU:VAL-91f83f
Reliable Ductile Iron Butterfly Valve with Lever Operation, DN125 PN6, FM Approved
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Ductile Iron Lever Operated Butterfly Valve DN125 PN6
$249.99
Quantity: 1
Claim Your Seller Account
Ductile Iron Lever Operated Butterfly Valve DN125 PN6
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series EVCS Lever Operated Ductile Iron Semi Lug Wafer Type DIN Butterfly Valve combines robust construction with precise engineering. This valve, with a DN125 size and PN6 rating, offers reliable performance in isolating and regulating flow. Crafted from high-quality materials like Ductile Iron and EPDM liner, it ensures durability and efficient operation. With an ISO 5211 F07 standard mounting pad and FM approval, it provides ease of installation and compliance with safety regulations. Suitable for various applications, this valve is a dependable choice for discerning buyers looking for performance and longevity.
Product Specifications
Specifications A
125 mm
Specifications Actuation Possibilities
Lever
Specifications Available Type Approvals
FM
Specifications Body Material
Ductile Iron
Specifications B Diameter
182 mm
Specifications C
56 mm
Specifications D
109 mm
Specifications E
160 mm
Specifications F
12 mm
Specifications Flange Connections
PN 6
Specifications G
34 mm
Specifications H Diameter
12 mm
Specifications Iso 5211
F07
Specifications K
70 mm
Specifications L
90 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM)
Specifications M Diameter
9 mm
Specifications N Number Of Holes
4
Specifications Shaft Material
Aluminum Bronze
Specifications Size
DN125 - 5" | 125 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 6 bar
Specifications Weight
7.0 kg
Specifications X
112 mm
Specifications Y
35 mm
