Dunkermotoren BG Series 11A Brushless DC Motor with Integrated Control Electronics
Dunkermotoren BG Series 11A Brushless DC Motor with Integrated Control Electronics
SKU:BGS-78e882
Achieve precision and efficiency with Dunkermotoren's BG Series 11A Brushless DC Motor for industrial applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Dunkermotoren BG Series 11A Brushless DC Motor with Integrated Control Electronics
$349.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BG Series 11A Brushless DC Motor with Integrated Control Electronics
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your industrial operations with the Dunkermotoren BG Series Brushless DC Motor featuring integrated control electronics. With a nominal current of 11A and 103W nominal output power, this motor offers precise speed, positioning, and current control. Compliance with IP65 protection and standards like CQC, CE, and UL ensures reliability and safety in your applications. Experience efficient performance, overload protection, and Smart Diagnostics for streamlined operations.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsProfinet version availableEtherCAT version availableEtherNet/IP version availableIO modeSpeed modeCurrent modePositioningDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelBallast circuitHigh efficiencySinusoidal vector controlInterpolationSSI version availableSafe torque off versionS-RampeOperating hours
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
271 W
Technical Specs Direct Current Dc Voltage Range
2 to 58 V
Technical Specs Feedback Integrated
4096 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
160 W
Technical Specs Maximum Torque
0.82 N·m
Technical Specs Nominal Current
11 A
Technical Specs Nominal Direct Current Dc Voltage
12 V
Technical Specs Nominal Output Power
103 W
Technical Specs Nominal Speed
2800 rpm
Technical Specs Nominal Torque
0.35 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Direct Current Dc Voltage
Preliminary data
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
3810 rpm
Technical Specs Peak Power
732 W
Technical Specs Product Availability
Standard Product
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
70 g/cm²
Technical Specs Torque Constant
0.045 N·mA-1
Technical Specs Weight Of Motor
1.2 kg
