Dunkermotoren BG Series 2.08A Brushless DC Motor
Dunkermotoren BG Series 2.08A Brushless DC Motor
SKU:BGS-c7df5e
Experience precision and efficiency with the Dunkermotoren BG Series 2.08A Brushless DC Motor. UL compliant and modular for versatile applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Dunkermotoren BG Series 2.08A Brushless DC Motor
$129.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BG Series 2.08A Brushless DC Motor
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren BG Series 2.08 Ampere Brushless DC Motor is a high-performance motor designed for precision and efficiency. With integrated commutation electronics, neodymium magnets, and bipolar 3-wire version, it ensures exceptional power density and overload capability. This motor boasts features like long lifetime, dynamic acceleration, wide speed range, and maintenance-free operation. Compliant with UL standards, it offers market-oriented solutions with modular compatibility for control electronics, gearboxes, brakes, and encoders.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Combined in a modular system with control electronics, gearboxes, brakes and encoders, these electronically commutated DC motors provide a flexible, adaptable, market-oriented solution.Alternatively, these motors are also available with integrated speed and positioning electronics (see dMove and dPro)Particularly smooth running is the motor BGA 22No cogging torque/ coreless designLow noise levelThis motor is on request available in different voltage versions
Features Features
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:Very long lifetimeHigh efficiencyHighly dynamic accelerationOptimized control characteristicsWide speed rangeHigh power densityMaintenance-freeRobust designHigh overload capabilityLow moment of inertiaMotor insulation - Class ENeodymium magnetsSpeed set input (6-wire version)Bipolar (3-wire version)Block commutationDigital inputsDigital outputsAnalog inputsPremium efficiencyVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
24 W
Technical Specs Feedback Integrated
18 cycles/rev
Technical Specs Industry Standardscertifications
Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
34 W
Technical Specs Nominal Current
2.08 A
Technical Specs Nominal Direct Current Dc Voltage
6 V
Technical Specs Nominal Output Power
6.20 W
Technical Specs Nominal Speed
2990 rpm
Technical Specs Nominal Torque
0.020 N·m
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Direct Current Dc Voltage
Not available as 2-/ 3 wire-version
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Stall Torque
ÏR = 20ºC
Technical Specs Note For Torque Constant
Only for hall version
Technical Specs No Load Speed
5500 rpm
Technical Specs Peak Current
8 A
Technical Specs Peak Power
236 W
Technical Specs Product Availability
Standard Product
Technical Specs Protection Class
Ingress Protection (IP40)
Technical Specs Rotor Inertia
15 g/cm²
Technical Specs Stall Torque
0.059 N·m
Technical Specs Torque Constant
0.011 N·mA-1
Technical Specs Weight Of Motor
0.065 kg
