Dunkermotoren BG Series 3.3A Brushless DC Motor
Dunkermotoren BG Series 3.3A Brushless DC Motor
SKU:BGS-a40bcb
Highly dynamic and efficient BG Series 3.3A DC Motor for industrial applications. Compliant with UL standards.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
Dunkermotoren BG Series 3.3A Brushless DC Motor
$149.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BG Series 3.3A Brushless DC Motor
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren BG Series Brushless DC Motor offers a highly dynamic, efficient, and maintenance-free solution for a wide range of industrial applications. With a nominal power of 64W and IP40 protection class, it combines premium efficiency with robust design. Featuring neodymium magnets, digital inputs, and a wide speed range, this motor ensures optimal performance and longevity. Compliant with industry standards like Underwriters Laboratories (UL), it is adaptable and compatible with various control electronics and accessories, making it a versatile choice for institutional buyers.
Product Specifications
Additional Information Additional Information
Combined in a modular system with control electronics, gearboxes, brakes and encoders, these electronically commutated DC motors provide a flexible, adaptable, market-oriented solution.Alternatively, these motors are also available with integrated speed and positioning electronics (see dMove and dPro)Particularly smooth running is the motor BGA 22No cogging torque/ coreless designLow noise levelThis motor is on request available in different voltage versions
Features Features
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:Very long lifetimeHigh efficiencyHighly dynamic accelerationOptimized control characteristicsWide speed rangeHigh power densityMaintenance-freeRobust designHigh overload capabilityLow moment of inertiaMotor insulation - Class ENeodymium magnetsSpeed set input (6-wire version)Bipolar (3-wire version)Block commutationDigital inputsDigital outputsAnalog inputsPremium efficiencyVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
64 W
Technical Specs Feedback Integrated
24 cycles/rev
Technical Specs Industry Standardscertifications
Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
110 W
Technical Specs Nominal Current
3.3 A
Technical Specs Nominal Direct Current Dc Voltage
24 V
Technical Specs Nominal Output Power
64 W
Technical Specs Nominal Speed
3670 rpm
Technical Specs Nominal Torque
0.166 N·m
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Stall Torque
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
4120 rpm
Technical Specs Peak Current
6.5 A
Technical Specs Peak Power
110 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP40)
Technical Specs Rotor Inertia
44 g/cm²
Technical Specs Stall Torque
0.445 N·m
Technical Specs Torque Constant
0.061 N·mA-1
Technical Specs Weight Of Motor
0.47 kg
