Dunkermotoren BG Series 7.3A Brushless DC Motor
Dunkermotoren BG Series 7.3A Brushless DC Motor
SKU:BGS-941906
Cutting-edge 7.3A DC motor with high precision control and advanced features for industrial applications.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Dunkermotoren BG Series 7.3A Brushless DC Motor
$799.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BG Series 7.3A Brushless DC Motor
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren BG Series 7.3 Ampere Brushless DC Motor with 306 Watt Output Power offers cutting-edge technology for precise control and high performance. Featuring integrated control electronics, this motor supports advanced features like field-oriented control (FOC), positional accuracy with a 4096 cpr magnetic encoder, and programmable functionalities. Ideal for applications requiring speed, positioning, and current control, it boasts IP65 protection, overload protection, and compatibility with various add-ons like encoders and gearboxes. Meeting industry standards such as CE and UL certifications, this motor ensures reliability and efficiency in diverse settings.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsCANopen version availableIO modeSpeed modeCurrent modePositioningBlock commutationDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelBallast circuitHigh efficiencyOperating hoursVibration resistanceEPLAN Data Portal
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
306 W
Technical Specs Direct Current Dc Voltage Range
2 to 58 V
Technical Specs Feedback Integrated
4096 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
732 W
Technical Specs Maximum Torque
3.06 N·m
Technical Specs Nominal Current
7.3 A
Technical Specs Nominal Direct Current Dc Voltage
48 V
Technical Specs Nominal Output Power
306 W
Technical Specs Nominal Speed
3490 rpm
Technical Specs Nominal Torque
0.84 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Peak Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
3750 rpm
Technical Specs Peak Current
20.1 A
Technical Specs Peak Power
732 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
188 g/cm²
Technical Specs Torque Constant
0.13 N·mA-1
Technical Specs Weight Of Motor
2.1 kg
