Experience unparalleled efficiency with Dunkermotoren's BG Series Brushless DC Motors. Ideal for dynamic acceleration and wide speed range. Maintenance-free and robust design.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Dunkermotoren BG Series Brushless DC Motor
$299.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BG Series Brushless DC Motor
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren BG Series Brushless DC Motors with Integrated Hall Sensors are engineered for superior performance in dynamic applications. With a nominal output power of 79W and a nominal current of 9.51A, these motors offer exceptional efficiency, high power density, and maintenance-free operation. Featuring neodymium magnets and a robust design, they provide high overload capability and vibration resistance. Moreover, these motors can be tailored to meet various voltage requirements, making them a versatile and reliable choice for industrial applications.
Product Specifications
Additional Information Additional Information
Combined in a modular system with control electronics, gearboxes, brakes and encoders, these electronically commutated DC motors provide a flexible, adaptable, market-oriented solution.
Features Features
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:Very long lifetimeHigh efficiencyHighly dynamic accelerationOptimized control characteristicsWide speed rangeHigh power densityMaintenance-freeRobust designHigh overload capabilityLow moment of inertiaMotor insulation - Class ENeodymium magnetsHigh efficiencyVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
181 W
Technical Specs Feedback Integrated
30 cycles/rev
Technical Specs Industry Standardscertifications
Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
79 W
Technical Specs Maximum Torque
0.58 N·m
Technical Specs Nominal Current
9.51 A
Technical Specs Nominal Direct Current Dc Voltage
12 V
Technical Specs Nominal Output Power
79 W
Technical Specs Nominal Speed
3530 rpm
Technical Specs Nominal Torque
0.214 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
7330 rpm
Technical Specs Peak Power
355 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
71.6 g/cm²
Technical Specs Torque Constant
0.031 N·mA-1
Technical Specs Weight Of Motor
0.87 kg
