The Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors is a highly dynamic 3-phase EC motor designed for precision and efficiency. With continuous power of 181W and a peak power of 355W, this motor operates at 24V with a nominal current of 5.03A. Meeting Ingress Protection (IP65) standards, this motor ensures reliable performance in demanding environments. Its features include a neodymium magnet, optimized control characteristics, and maintenance-free operation, making it ideal for institutional applications requiring high efficiency and longevity.
Product Specifications
Additional Information Additional Information
Combined in a modular system with control electronics, gearboxes, brakes and encoders, these electronically commutated DC motors provide a flexible, adaptable, market-oriented solution.
Features Features
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:Very long lifetimeHigh efficiencyHighly dynamic accelerationOptimized control characteristicsWide speed rangeHigh power densityMaintenance-freeRobust designHigh overload capabilityLow moment of inertiaMotor insulation - Class ENeodymium magnetsHigh efficiencyVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
181 W
Technical Specs Feedback Integrated
30 cycles/rev
Technical Specs Industry Standardscertifications
Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
103 W
Technical Specs Maximum Torque
0.58 N·m
Technical Specs Nominal Current
5.03 A
Technical Specs Nominal Direct Current Dc Voltage
24 V
Technical Specs Nominal Output Power
90 W
Technical Specs Nominal Speed
4170 rpm
Technical Specs Nominal Torque
0.270 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
7970 rpm
Technical Specs Peak Power
355 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
71.6 g/cm²
Technical Specs Torque Constant
0.057 N·mA-1
Technical Specs Weight Of Motor
0.87 kg
