The Dunkermotoren BG Series 5.2A Brushless DC Motor boasts a seamless integration of a 4Q servo controller and high-resolution encoder system, ensuring precise control and efficient operation. With variants catering to PROFINET, EtherCAT, and EtherNet/IP protocols, this motor offers versatile connectivity options for various industrial applications. Its robust construction and IP65 protection class provide resistance against water and contaminants, while incorporating features like Safe Torque Off for enhanced safety. Designed for seamless integration with encoders, brakes, and gearboxes, this motor is programmable through Motion Code and offers Smart Diagnostics for easy monitoring. The Dunkermotoren BG Series complies with CE, UL, and CQC standards to meet stringent quality and safety requirements.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsProfinet version availableEtherCAT version availableEtherNet/IP version availableIO modeSpeed modeCurrent modePositioningDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelBallast circuitHigh efficiencySinusoidal vector controlInterpolationSSI version availableSafe torque off versionS-RampeOperating hours
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
271 W
Technical Specs Direct Current Dc Voltage Range
2 to 58 V
Technical Specs Feedback Integrated
4096 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
485 W
Technical Specs Maximum Torque
1.75 N·m
Technical Specs Nominal Current
5.2 A
Technical Specs Nominal Direct Current Dc Voltage
48 V
Technical Specs Nominal Output Power
220 W
Technical Specs Nominal Speed
3350 rpm
Technical Specs Nominal Torque
0.56 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Peak Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
3760 rpm
Technical Specs Peak Current
14 A
Technical Specs Peak Power
732 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
129 g/cm²
Technical Specs Torque Constant
0.12 N·mA-1
Technical Specs Weight Of Motor
1.65 kg
