The Dunkermotoren BG Series Brushless DC Motor with Integrated Control Electronics is a high-performance motor designed for precision operations. With a Nominal Current of 22.07 A and Nominal Output Power of 468 W, this motor offers reliable and efficient performance. It features integrated control electronics, high-resolution encoder system, and multiple variants for different network protocols. The motor is programmable, offers inherent overload protection, and can be easily integrated with encoders, brakes, and gearboxes. With IP65 protection and compliance with industry standards like CE, UL, and CQC, this motor is ideal for industrial and institutional applications.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsProfinet version availableEtherCAT version availableEtherNet/IP version availableIO modeSpeed modeCurrent modePositioningDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelOperating hoursHigh efficiencySinusoidal vector controlInterpolationSSI version availableSafe torque off versionS-RampeOperating hours
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
405 W
Technical Specs Direct Current Dc Voltage Range
3 to 58 V
Technical Specs Feedback Integrated
4096 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
812 W
Technical Specs Maximum Torque
2.76 N·m
Technical Specs Nominal Current
22.07 A
Technical Specs Nominal Direct Current Dc Voltage
24 V
Technical Specs Nominal Output Power
468 W
Technical Specs Nominal Speed
4040 rpm
Technical Specs Nominal Torque
1.106 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Peak Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
4460 rpm
Technical Specs Peak Current
41.7 A
Technical Specs Peak Power
1700 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
437 g/cm²
Technical Specs Torque Constant
0.063 N·mA-1
Technical Specs Weight Of Motor
2.5 kg
