Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors
Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors
SKU:BGS-1e994b
Powerful & efficient Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors for dynamic acceleration & wide speed range.
Regular price
$179.99
Regular price
Sale price
$179.99
Unit price
per
Initiate Order
Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors
$179.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors
$179.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience the Dunkermotoren BG Series Brushless DC Motor with Integrated Hall Sensors, designed for exceptional performance and reliability. With a nominal current of 2.04A and an output power of 86.6W, this motor offers highly dynamic acceleration, efficient operation, and a wide speed range. Featuring neodymium magnets, robust construction, and maintenance-free operation, this motor ensures longevity and high efficiency. Compliant with industry standards like China Quality Certification (CQC) and Underwriters Laboratories (UL), it meets the rigorous demands of institutional procurement.
Product Specifications
Additional Information Additional Information
Combined in a modular system with control electronics, gearboxes, brakes and encoders, these electronically commutated DC motors provide a flexible, adaptable, market-oriented solution.
Features Features
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:Very long lifetimeHigh efficiencyHighly dynamic accelerationOptimized control characteristicsWide speed rangeHigh power densityMaintenance-freeRobust designHigh overload capabilityLow moment of inertiaMotor insulation - Class ENeodymium magnetsHigh efficiencyVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
181 W
Technical Specs Feedback Integrated
30 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
95 W
Technical Specs Maximum Torque
0.58 N·m
Technical Specs Nominal Current
2.04 A
Technical Specs Nominal Direct Current Dc Voltage
60 V
Technical Specs Nominal Output Power
86.6 W
Technical Specs Nominal Speed
3530 rpm
Technical Specs Nominal Torque
0.234 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
7330 rpm
Technical Specs Peak Power
355 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
71.6 g/cm²
Technical Specs Torque Constant
0.155 N·mA-1
Technical Specs Weight Of Motor
0.87 kg
