Experience optimal performance and control with the Dunkermotoren BG Series Brushless DC Motor. This motor boasts a Nominal Output Power of 386W and a Nominal Current of 18.63A, ensuring efficient operation. With integrated control electronics, advanced features such as Speed, Positioning, and Current Control, and high IP protection, this motor offers versatility and reliability. Certified with China Quality Certification (CQC), European Conformity (CE), and Underwriters Laboratories (UL) standards, it meets the stringent quality requirements for government and institutional procurement.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsCANopen version availableIO modeSpeed modeCurrent modePositioningBlock commutationDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelBallast circuitHigh efficiencyOperating hoursVibration resistanceEPLAN Data Portal
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
480 W
Technical Specs Direct Current Dc Voltage Range
2 to 58 V
Technical Specs Feedback Integrated
24 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
766 W
Technical Specs Maximum Torque
3.51 N·m
Technical Specs Nominal Current
18.63 A
Technical Specs Nominal Direct Current Dc Voltage
24 V
Technical Specs Nominal Output Power
386 W
Technical Specs Nominal Speed
3470 rpm
Technical Specs Nominal Torque
1.062 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Peak Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
4000 rpm
Technical Specs Peak Current
41.20 A
Technical Specs Peak Power
1029 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
652 g/cm²
Technical Specs Torque Constant
0.069 N·mA-1
Technical Specs Weight Of Motor
2.8 kg
