Dunkermotoren BR Series Braking Choppers
Dunkermotoren BR Series Braking Choppers
SKU:BRS-561cf8
Ensure motor system safety with Dunkermotoren BR Series Braking Choppers. Adjustable voltage range, high pulse current, and integrated capacitor for reliable performance.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Dunkermotoren BR Series Braking Choppers
$299.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren BR Series Braking Choppers
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren BR Series Braking Choppers provide efficient protection against voltage peaks during motor braking. With the capability to be connected in parallel with the power supply, these choppers offer a customizable maximum permissible voltage range of +18 to 60 V through intuitive switch settings. Featuring a maximum pulse current of 60 A, integrated 400µF capacitor, and external braking resistor requirement, these choppers ensure smooth and safe motor braking operations in diverse industrial settings.
Product Specifications
Technical Specs Braking Resistor
Must be Connected Externally
Technical Specs Brands
Dunkermotoren
Technical Specs Direct Current Dc Voltage Range To Be Set
+18 to 60 V
Technical Specs Integrated Capacitor
400 µF
Technical Specs Maximum Pulse Current
60 A
Technical Specs Series
BR
