Dunkermotoren GR Series 707W Brushed DC Motor
Dunkermotoren GR Series 707W Brushed DC Motor
SKU:GRS-c237c1
Powerful Dunkermotoren GR Series motor for high-performance applications with IP54 protection and compliance with CE, CQC, and UL standards.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Dunkermotoren GR Series 707W Brushed DC Motor
$299.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren GR Series 707W Brushed DC Motor
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren GR Series 6.2A Nominal Current and 707W Maximum Output Power Brushed DC Motor is engineered for precision and durability. With IP54 protection and optional IP67 upgrade, this motor is designed for longevity and efficiency. Featuring high torque, low inertia, and robust construction, it ensures reliable performance in demanding applications. Compliant with CE, CQC, and UL standards, it offers a low-noise, maintenance-free solution with high overload capacity and interference suppression.
Product Specifications
Additional Information Additional Information
The DC motors can be combined with control electronics, gearboxes, brakes and encoders in a modular system to provide a flexible, adaptable, market-oriented solution.
Features Features
The Dunkermotoren GR range (commutated DC motors) are notable for:Longer life than commutated motors from other manufacturersLow detent torquesHigh efficiencyHigh dynamic accelerationGood regulation characteristicsMaintenance-freeRobust designLow moment of inertiaExtremely high short time overload capacity of the motorSurface protectionMinimum interference radiation, optionalinterference suppressionHigh quality due to fully automated production linesLow noiseSpecial surfaceInterference suppression optionalVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
224 W
Technical Specs Demagnetisation Current
⥠51 A
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
707 W
Technical Specs Maximum Torque
6.01 N·m
Technical Specs Nominal Current
6.2 A
Technical Specs Nominal Direct Current Dc Voltage
40 V
Technical Specs Nominal Output Power
208 W
Technical Specs Nominal Speed
2970 rpm
Technical Specs Nominal Torque
0.67 N·m
Technical Specs Note For Demagnetisation Current
ÏR = 20ºC
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Current
ÏR = 20ºC
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Stall Torque
ÏR = 20ºC
Technical Specs Note For Starting Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Current
0.37 A
Technical Specs No Load Speed
3050 rpm
Technical Specs Peak Power
817 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP54)
Technical Specs Rotor Inertia
3200 g/cm²
Technical Specs Stall Torque
8.85 N·m
Technical Specs Starting Current
75 A
Technical Specs Terminal Inductance
3.73 mH
Technical Specs Terminal Resistance
0.533 Ω
Technical Specs Torque Constant
0.118 N·mA-1
Technical Specs Weight Of Motor
4.0 kg
