Dunkermotoren High-Performance Linear Motor SL Series
Dunkermotoren High-Performance Linear Motor SL Series
SKU:LIN-ee1840
Revolutionize industrial automation with Dunkermotoren's SL Series 2255N Peak Force Linear Motor. High-power efficiency for precise motion control.
Regular price
$2,799.99
Regular price
Sale price
$2,799.99
Unit price
per
Initiate Order
Dunkermotoren High-Performance Linear Motor SL Series
$2,799.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren High-Performance Linear Motor SL Series
$2,799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren SL Series 2255N Peak Force Linear Motor offers unparalleled precision, reliability, and efficiency for industrial applications. With a peak current of 26A, nominal voltage of 325V, and advanced features like water cooling compatibility and integrated linear encoder, this motor ensures optimal performance in dynamic environments. It meets European Conformity (CE) and IP65 standards, making it ideal for federal procurement, GSA requirements, and FAR compliance.
Product Specifications
Features Features
Force modePrecise positioningMaintenance freeLow noiseHigh ForceHigh dynamicFood gradeSpecial SurfaceVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
615 W
Technical Specs Feedback Integrated
Bidirectional Serial Synchronous (BISS) | Synchronous Serial Interface (SSI) | Transistor-Transistor Logic (TTL)
Technical Specs Forcer Mass
5.0 kg
Technical Specs Force Constant At 25 Degree Celsius C Temperatur
87.9 pk
Technical Specs Industry Standardscertifications
European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Speed At 100 Degree Celsius C Temperatur
2.9 m/s
Technical Specs Nominal Current At 100 Degree Celsius C Temperat
2.4 A
Technical Specs Nominal Direct Current Dc Voltage
325 V
Technical Specs Nominal Force At 100 Degree Celsius C Temperatur
211 N
Technical Specs Note For Maximum Speed At 100 Degree Celsius C T
Moving motor housing with 2xxx mm stroke
Technical Specs Note For Peak Acceleration At 100 Degree Celsius
Moving magnetic rod with 2x mm stroke
Technical Specs Note For Peak Acceleration Sl 38 C
Moving motor housing with 2xxx mm stroke
Technical Specs Peak Acceleration At 100 Degree Celsius C Temper
>200 m/s²
Technical Specs Peak Current At 25 Degree Celsius C Temperature
26 A
Technical Specs Peak Force At 25 Degree Celsius C Temperature
2255 N
Technical Specs Peak Power
3690 W
Technical Specs Pole Pitch
51.2 mm
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rod Mass
8.3 kg/m
