Dunkermotoren KD Series 0.122 N·m AC Motor
Dunkermotoren KD Series 0.122 N·m AC Motor
SKU:KDD-e33a77
Experience durability and efficiency with the Dunkermotoren KD Series AC Motor, featuring a rugged design and optimal cooling for reliable performance.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Dunkermotoren KD Series 0.122 N·m AC Motor
$299.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren KD Series 0.122 N·m AC Motor
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren KD Series AC Motor delivers reliable performance with a rugged design, maintenance-free operation, and optimal cooling. With a nominal torque of 0.122 N·m and industry-leading standards such as IP54 protection and UL certification, this motor ensures durability and efficiency. Designed for vibration resistance and compatibility with gearboxes and brakes, it meets the highest institutional procurement requirements.
Product Specifications
Additional Information Additional Information
Can be combined with gearboxes and brakesIP 44 protected when flange-mountedInsulation material according to VDE 0530, corresponds to insulation class ESurface protected by passivated housing
Features Features
Vibration resistance
Phase Shifting Capacitor1 Capacitance Cb
4 µF
Phase Shifting Capacitor1 Voltage Uc
~260 V
Technical Specs Brands
Dunkermotoren
Technical Specs Connection Type
Delta (Î)
Technical Specs Frequency
50 Hz | 60 Hz
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | Underwriters Laboratories (UL)
Technical Specs Moment Of Intertia J
280 g/cm²
Technical Specs Nominal Output Power Pn
34 W
Technical Specs Nominal Speed Nn
2700 rpm
Technical Specs Nominal Torque Mn
0.122 N·m
Technical Specs Nominal Voltage
230 V
Technical Specs Note For Frequency
For 50 Hz operation. Not included in scope of delivery
Technical Specs Power
34 to 44 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP54)
Technical Specs Pull Out Torque Mk
0.168 N·m
Technical Specs Rated Current In
0.30 A
Technical Specs Starting Torque Ma
0.076 N·m
Technical Specs Weight M B 14 Din 42950
1.6 kg
