Dunkermotoren NG Series 5 Gearbox with 16Nm Continuous Torque

Name: Dunkermotoren NG Series 5 Gearbox with 16Nm Continuous Torque
Brand: Dunkermotoren
SKU: NGS-b19510
Price: 699.99 USD
Availability: OutOfStock

SKU:NGS-b19510

Experience top-notch efficiency and durability with the Dunkermotoren NG Series 5 Gearbox. Ideal for high-performance applications.

$699.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Dunkermotoren NG Series 5 Gearbox features a reduction ratio of 5, delivering a continuous torque of 16 N·m with exceptional efficiency of 90%. Designed with a durable and robust construction, this gearbox requires minimal installation space as it is integrated in the hub. With a maximum backlash of 45 arc-min and weighing 7.8 kg, it offers high radial load capacity and axial load resistance, making it ideal for demanding applications. Additionally, it comes with lifetime lubrication, high torque capabilities, and vibration resistance for a reliable performance and long service life.

Product Specifications

Features Features

Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version

Technical Specs Acceleration Torque

32 NÂ·m

Technical Specs Axial Load

1667 N

Technical Specs Brands

Dunkermotoren

Technical Specs Continuous Torque

16 NÂ·m

Technical Specs Efficiency

90 %

Technical Specs Emergency Stop Torque

48 NÂ·m

Technical Specs Maximum Backlash

45 arc-min

Technical Specs Number Of Stages

Technical Specs Operating Mode

S1 | S8

Technical Specs Product Availability

Standard Product

Technical Specs Protection Class

Ingress Protection (IP54)

Technical Specs Radial Load

5000 N

Technical Specs Reduction Ratio

Technical Specs Series

Technical Specs Weight Of Gearbox

7.8 kg
